High-Speed Differential Probe Series HSDP
■ >4GHz bandwidth, low noise,1MΩ || 0,6pF input
■ ±8V, ±20V, ±42V models
■ ±60V common mode voltage
■ Ideal for debugging and verificationof serial busses
■ Up to 7.5m cable length forreaching test points far away
About the HSDP Series
The HSDP series offers best-in-class performance with >2GHz models up to ±42V differential input range, and ±8V models up to >4GHz bandwidth. The high input impedance, low noise, and 60V common mode voltage range the different models ideal for various in-circuit measurements for design, validation, debugging of analog signals, such as used in switched mode power supplies. The HSDP probes series is also ideal for characterizing a wide range of serial bus designs, supporting the most popular serial bus interfaces, such as USB2.0, Ethernet (GbE), CAN/LIN, I2C, SPI, SATA, FireWire (1394b), FlexRay, HDMI etc.
The HSDP Series features the industry standard 2.54mm (0.1") socketed inputs that can easily interface to a variety of connectivity options available in the market. The compact probe head design, and its variety of accessories, makes the HSDP Series ideal for probing on today’s smallest IC devices.
The ±12V input offset capability extends the dynamic input range of the probe. Having an input impedance of 1MΩ || <0.6pF between the probe tips, allows the HSDP Series to be used to probe sensitive circuits without adversely loading the circuit under test.
All models are available with either a 7.5m or 2m cable length. These longer cable versions enable the user to probe remote, hard to reach test points that are impossible with the other probing solution in the market today.
The HSDP Series has a universal BNC output connector and is compatible with any oscilloscope with a 50Ω input impedance, or 1MΩ input impedance and a 50Ω feed-through termination, allowing the HSDP Series to be used on any oscilloscope in the lab.
HSDP Series’ DC offset can be controlled via remote control.
A PMK power supply unit is required. These are available with a USB interface and are optionally available with a LAN interface. Remote control of the probe is made possible by the power supply unit.
The exact range of functions of the probes is described on the page linked below for the respective software solution.
Several software solutions are available for remote control of PMK products:
The 1 channel battery pack power supply AP-01 provides >8h of portable and isolated operation, which allows the user the flexibility of where the probe can be used.
The AP-01 supplies power only to the probe with no software remote control.
Find out more about AP-01 here.
ISO17025 calibration upon delivery or as re-calibration is available on request.
Demo the HSDP2025?
We currently have an HSDP2050 available as a demo unit. You can choose between a virtual demo or have a unit shipped directly to you. We typically ship demos for a duration of about two weeks. Currently limited to customers in the United States. For other regions, please visit pmk.de.
Interested? Email us at sales@pmkamerica.com to request your demo today.
Models & Specifications
| Model number | Attn. Ratio (± 2 % at DC) | B/W | Differential Voltage Range (DC + AC peak) | Differential DC Offset Range | |||
|---|---|---|---|---|---|---|---|
|
HSDP4010 | 10:1 | > 4 GHz 4.2 GHz (typ.) | ± 8 V (16 Vpp) | ± 12 V | ||
|
HSDP2010 | 10:1 | > 2 GHz 2.3 GHz (typ.) | ± 8 V (16 Vpp) | ± 12 V | ||
|
HSDP2050 | 50:1 | > 2 GHz 2.2 GHz (typ.) | ± 42 V (84 Vpp) | ± 60 V | ||
|
HSDP2025 | 25:1 | > 2 GHz 2.2 GHz (typ.) | ± 20 V (40 Vpp) | ± 30 V | ||
|
HSDP2010L | 10:1 | > 1.8 GHz 2.0 GHz (typ.) | ± 8 V (16 Vpp) | ± 12 V | ||
|
HSDP2050L | 50:1 | > 1.8 GHz 2.0 GHz (typ.) preliminary | ± 42 V (84 Vpp) | ± 60 V | ||
|
HSDP2050M | 50:1 | > 1.8 GHz 2.0 GHz (typ.) preliminary | ± 42 V (84 Vpp) | ± 60 V | ||
|
HSDP2025L | 25:1 | > 1.8 GHz 2.0 GHz (typ.) | ± 20 V (40 Vpp) | ± 30 V | ||
Accessories for the HSDP Series
Please see the HSDP Series Datasheet to learn more about suitable accessories and its scope of delivery.
| Order number | Article | Bandwidth (-3dB) | |||
|---|---|---|---|---|---|
|
|
890-808-105 | 2-footer positioner, black | n/a | |
|
|
891-010-814 | Set of 10 PCB adapters | > 2.5 GHz | |
|
|
890-800-001 | Set of 5 Spring Tips | > 2.5 GHz | |
|
|
890-800-000 | Set of 5 Solid Tips | > 2.5 GHz | |
|
|
890-600-215 | Adapter UF.L with Micro coax cable | > 1.3 GHz | |
|
|
972416100 | Micro SMD-Clip (black) | > 0.5 GHz | |
|
|
890-010-912 | Set of cable coding rings 3x4 colors | n/a | |
|
|
890-400-808 | Ground lead 7cm | n/a | |
|
|
890-400-809 | Ground lead 13cm | n/a | |
|
|
890-520-900 | Probe connection cable 0.6 m | n/a | |
Power Supplies for the HSDP Series
Not included in the HSDP probe's scope of delivery. A power supply is needed to operate the HSDP probe head.
| Order number | Article | Input Voltage | Output Current (max.) | Noise | Channels | Power | |||
|---|---|---|---|---|---|---|---|---|---|
|
889-09V-AP01 | 1ch Battery pack, >8hrs operation, no remote control | 700 mA DC | 1 | 20 W | ||||
|
|
890-520-915 | Probe connection cable 1.6 m | ||||||
|
889-09V-PS2 | 2ch Power supply for remote control with USB interface | 100-240 V AC, 47-63 Hz | 550 mA / channel | 8 mV | 2 | 20 W | ||
|
889-09V-PS3 | 4ch Power supply for remote control with USB interface | 100-240 V AC, 47-63 Hz | 550 mA / channel | 4 mV | 4 | 40 W | ||
|
889-09V-PS3-L | 4ch Power supply for remote control with USB and LAN interface | 100-240 V AC, 47-63 Hz | 550 mA / channel | 4 mV | 4 | 40 W | ||
|
889-09V-PS2-L | 2ch Power supply for remote control with USB and LAN interface | 100-240 V AC, 47-63 Hz | 550 mA / channel | 8 mV | 2 | 20 W | ||
