PMK America - High-End Probing Solutions for Advanced Power Electronics

Ready to Ship from the USA – Buy Now for Immediate Delivery:

MSU 1500, 3D positioner with steel base, 200mm span width and universal probe holder

MSU 1500, 3D positioner with steel base, 200mm span width and universal probe holder

893-350-006

PMK America Corporation
$683.00 USD

MSU 1500, 3D positioner with steel base, 200mm span width and universal probe holder

Full details →
MSA 100, 3D positioner with steel base, 200mm span width, and holder for probes / 5-12mm

MSA 100, 3D positioner with steel base, 200mm span width, and holder for probes / 5-12mm

893-350-001

PMK America Corporation
$467.00 USD

MSA 100, 3D positioner with steel base, 200mm span width, and holder for probes / 5-12mm

Full details →

High Voltage Passive Probes

■ Ideal for switching power supplies, IGBTs, Si /SiC power components

■ 4000V input voltage, 100:1, >600MHz bandwidth, <3pF input capacitance, 50MΩ Input Impedance

■ Compact form factor

■ Variety of Accessories for individual Contacting

■ Universal Use with BNC Connector

■ Output Termination 1MΩ

■ For tester applications

Ultra-Fast Current Shunt UFCS

■ Market-leading >1GHz Bandwidth

■ Ultra-low <200 pH Insertion Inductance

■ Various sizes available: 1mΩ, 5mΩ, 11mΩ, 24mΩ, 52mΩ

■ For WBG switching loss and pulse current measurements

High Voltage Optically-Isolated Probe Series FireFly®

■ Ideal for GaN / SiC high-side
   VGS measurements

■ Best-in-class >1.5GHz bandwidth, <300ps rise time

■ Industry-leading ultra-low temperature drift of < 0.05%/°C

■ >180dB CMRR from DC to 500kHz, 80dB at 1GHz

■ ±60kV Common Mode Voltage

Try Our Demo Units

We offer a selection of demo units that are ready for immediate use. You can choose between a virtual demo or have a unit shipped directly to you. Demos typically run for about two weeks and are available to customers in the United States. For other regions, please visit pmk.de.

Interested? Email us at sales@pmkamerica.com to request your demo today.

MMCX Probe Series

■ Ideal for Test, Debug, and Design Validation

■ Up to >1GHz Bandwidth

■ ±42V Peak, 30V RMS, ±60V DC Input Voltage

■ As low as <4pF Input Capacitance

■ Large Variety of Tip Adapters and Accessories

■ Universal BNC - Use with any Oscilloscope

High-Speed Differential Probe Series HSDP

■ >4GHz bandwidth, low noise, 1MΩ || 0.6pF input​

■ ±8V, ±20V, ±42V models​

■ ±60V common mode voltage​

■ Ideal for debugging and verification of serial busses​

■ Up to 7.5m cable length or reaching test points far away​

High Voltage Differential Probe Series BumbleBee®

■ Ideal for switching power supplies & GaN / SiC power devices

■ ±200V, ±400V, ±1000V bis ±2000V models

■ Each with four user selectable Input attenuator ranges

■ 400MHz / 500MHz bandwidth

■ Up to 7m cable length for reaching test points far away

TETRIS® Series

■ Ideal for Multiple Contacting of adjacent Pins in 2.54 mm Pitch

■ Up to 2.5GHz Bandwidth

■ ±8V Dynamic Input Range

■ 20V Maximum Input Voltage

■ Variety of Accessories for individual Contacting

■ Plug-In Power Supply PS-01 inclusive

HORNET® Series

■ Ideal for switching power supplies, IGBTs, Si / SiC power devices

■ ±4000V Input voltage

■ Each with four user selectable input attenuator ranges

■ >300MHz bandwidth

■ High CMRR

■ For tester applications

Environmental Testing: ENVI® Probe

■ 350 MHz bandwidth

■ 300V CAT II, 400V / 1250V pk

■ Temperature range -55°C to +155°C

■ Reliant performance in harsh environments

Precision Wide-Band Current Transformers LILCO® Series

■ Bandwidth from 0.004Hz to >60MHz

■ Input currents from mA up to 25kA

■ Ultra low droop, High I-t capability

■ Very high DC saturation currents

SKID® Platforms

■ Hands-Free Testing

■ Compact & Robust Design

■ Modular Design

■ Up to -55°C to +155°C Models

■ Fast and Universal Setups

■ Intuitive Clamping System

Accessories for your daily measurements

■ Adjustment tools

■ Solid/spring tips & blades

■ Caps, BNC, PCB adapters

■ Ground leads, hooks, clips

■ Dual-lead to socket adapters

IWATSU® Rogowski Coil Current Probes

■ Best-in-class technology

■ Up to 100 MHz Wide Frequency Bandwidth

■ Extreme thin measuring coil diameter of just 1mm

■ 70+ different models available!
