$4,083.00 USD
PMK America Corporation

Ultra-fast current shunt, 24 mΩ | Pack of 10

UFCS-R024x10

made to order: 2 weeks lead time

24 mΩ, >1GHz bandwidth, 140pH insertion inductance, 70A maximum pulse current @ 100µs, SMA (F) output, 1pc. 10 pcs UFCS-R024 included.
